Product Parameters
| Parameter | Model：HF-CPUE-1A1B-BallSocket |
|---|---|
| Pouring Rate | 30～600 g/s |
| Raw Material Ratio | MOCA: 100:9~12; BDO: 100:3~6 |
| Tank Capacity | 50/100L |
| Mixing Head Speed | 8000–12000 r/min |
| Metering Accuracy | ≤±0.3%(Full range) |
| Tank Configuration | 1A1B two-component independent temperature control |
| Material Temperature Control | Tank A: 30~80℃; Tank B: MOCA(90~115℃)/BDO(25~50℃) |
| Vacuum Defoaming | Vacuum ≤-0.095MPa |
| Sistema de limpeza | Automatic circulation + air purge cleaning |
| Power | 5.5–7.5 kW |
| Sistema de controlo | PLC + touch screen + multi-formula storage |
| Applicable System | CPU Prepolymer + MOCA/BDO Chain Extender |
| Warranty | 1 year |
| Certifications | CE, ISO9001 |
Application Scenarios
Specially designed for the precision production of polyurethane steering shaft ball sockets for the automotive industry, widely suitable for the casting of passenger and commercial vehicle steering system parts. By switching MOCA/BDO formulas, it can achieve wear resistance, deformation resistance and high resilience, meeting the production requirements of high-precision assembly, long-term durability and stable steering for automotive parts.
Core Advantages
Dynamic full-range high-precision metering, small product size error, in line with automotive parts assembly standards.
Support MOCA/BDO dual chain extender switching, flexibly adjust hardness, suitable for different models of ball sockets.
Small-flow precise casting, stable forming without burrs, effectively improve the yield of small parts.
1A1B independent temperature control design, simple and stable operation, suitable for mass production of multi-specification auto parts.
