製品パラメーター
| パラメータ | Model：HF-HPM-2A2B-ColdRoom |
|---|---|
| 注入率 | 300～2000 g/s |
| 混合比 | Polyether: Isocyanate = 100:100~130 |
| タンク容量 | 200L / 300L（オプション、1タンクあたり） |
| ミキシングヘッド速度 | 8000～14000 r/分 |
| 投与精度 | ≤±0.3% (フルダイナミックレンジ) |
| タンク構成 | 2A2B Two-Component Independent Temp Control + Circulation Stirring |
| 温度管理 | 20～45℃ |
| 混合圧力 | 10～18MPa |
| 真空脱泡 | なし |
| 洗浄システム | Automatic Air Purge Cleaning (Solvent-Free & Eco-Friendly) |
| パワー | 11～15 kW |
| 制御システム | PLC + タッチスクリーン + マルチフォーミュラストレージ |
| アプリケーションシステム | ポリウレタン硬質フォーム断熱システム |
| 保証 | 1年 |
| 認証 | CE、ISO9001 |
アプリケーション・シナリオ
Specially designed for the insulation layer foaming of cold room panels, cold storage walls, refrigerated and frozen warehouses. It is suitable for large-scale cold storage engineering and prefabricated cold storage construction, meeting the core needs of high flame retardancy, low thermal conductivity, long-term thermal insulation, compression resistance and moisture resistance, adapting to large-scale production of cold storage building materials.
コアの利点
Large-flow pouring design, suitable for rapid foaming construction of large-area insulation layers in cold rooms.
High-pressure mixing molding, uniform rigid foam structure, dual compliance of thermal insulation and load-bearing performance.
Accurate two-component metering, high raw material utilization rate, reducing engineering construction cost.
Stable operation, suitable for mass construction needs of cold storage projects.
