製品パラメーター
| パラメータ | Model：HF-CPUE-2A2B-Cons-Road |
|---|---|
| 注入率 | 100～1800 g/s |
| 原材料比率 | Polyurethane Prepolymer : BDO Curing Agent = 100:4~7 |
| タンク容量 | 220 / 300 L |
| ミキシングヘッド速度 | 6000～10000 r/min |
| ダイナミック測光の精度 | ≤±0.5% (Full range) |
| タンク構成 | 2A2B two-component + wear-resistant additive tank |
| 材料の温度制御 | Tank A: 30~80℃; Tank B(BDO): 25~50℃ |
| Pouring Pressure | 0.8～2.5 MPa |
| 洗浄システム | High-pressure circulation cleaning + air purge cleaning |
| パワー | 7.5～15 kW |
| 制御システム | PLC + touch screen + multi-formula storage |
| 適用システム | Polyurethane Elastomer System |
| 保証 | 1年 |
| 認証 | CE, ISO9001, Highway Engineering Certification |
アプリケーション・シナリオ
Specially designed for polyurethane elastomer pouring of construction road engineering, suitable for road leveling, crack sealing, damage repair and waterproof layer pouring. It meets the core requirements of fast curing, wear resistance, rolling resistance and strong bonding, can withstand construction vehicle rolling, outdoor temperature changes and rain erosion, and firmly bonds with asphalt/concrete roads to prevent crack expansion and water intrusion, improve road flatness and service life, adapt to large-scale efficient construction, and shorten closed maintenance time.
コアの利点
2A2B configuration with wear-resistant additives, excellent wear and rolling resistance, can withstand heavy construction vehicle loads, suitable for high-load road conditions.
BDO fast curing formula, fast room temperature curing and short maintenance time, without delaying construction progress and road traffic.
Precise pouring is suitable for wide cracks and large-area leveling, full filling without voids, high road flatness and stable construction quality.
The machine is easy to move and clean, suitable for complex construction site environments, with precise temperature control and metering to ensure construction consistency.
