Product Parameters
| Parameter | Model：HF-RIM-1A1B-BuildingParts |
|---|---|
| Pouring Rate | 100～2000 g/s |
| Mix Ratio | Polyether: Isocyanate = 100:90~110 |
| Tank Capacity | 200L / 300L (Optional, Per Tank) |
| Dosing Accuracy | ≤±0.3% (Full Dynamic Range) |
| Tank Configuration | 1A1B Two-Component Independent Temp Control + Circulation Stirring |
| Temperature Control | 25～45℃ |
| Mixing Pressure | 150～200 bar |
| Venting System | Mold Negative Pressure Venting + High-Pressure Homogenization |
| Cleaning System | High-Pressure Circulation Cleaning + Air Purging |
| Power | 15～22 kW |
| Control System | PLC + Touch Screen + Multi-Formula Storage |
| Application System | Fiber-reinforced structural polyurethane RIM composites |
| Warranty | 1 Year |
| Certification | CE, ISO9001 |
Application Scenarios
Suitable for the production of prefabricated exterior wall components, architectural decorative parts, and large-scale lightweight structural parts. Using fiber-reinforced formula, the finished products have the characteristics of light weight, high strength, weather resistance, anti-aging and dimensional stability, meeting the production needs of modern prefabricated buildings.
Core Advantages
Suitable for fiber-reinforced structural formulas, with light weight, compression resistance and weather resistance, meeting building standards.
Large-flow stable discharge, which can meet the overall pouring molding of large-shaped building components.
High-precision metering closed-loop control, small deformation of finished products and higher dimensional uniformity.
One-key switching of multiple formulas, flexibly adapting to batch production of various types of building composite components.
